High Precision Battery Internal Resistance Tester for Lithium Battery Cell & Battery Pack Testing | AC Internal Resistance & DC Voltage Measurement up to 60V

Nombre De La Marca:	HongCe
Número De Modelo:	HC-A523
Cuota De Producción:	1 juego
Precio:	Negociable
Condiciones De Pago:	LC, T/T, D/P
Capacidad De Suministro:	1 juego de 7 días

Información detallada

Descripción de producto

Información detallada

Lugar de origen:

Porcelana

Certificación:

Calibration certificate(cost additional)

Exactitud de la resistencia interna:

±0,3%

exactitud del voltaje:

±0,05%

Gama de la resistencia interna:

0,001 mΩ – 3,2 kΩ

Rango de voltaje:

0V – 60V

Velocidad de prueba:

3, 15, 50 mediciones/segundo

Fuente de alimentación:

CA 190 V–256 V, 47 Hz–63 Hz

Potencia nominal:

15VA

Dimensiones:

385*249*102mm

Detalles de empaquetado:

madera contrachapada

Descripción de producto

High Precision Battery Internal Resistance Tester for Lithium Battery Cell & Battery Pack Testing | AC Internal Resistance & DC Voltage Measurement up to 60V

High Precision Battery Internal Resistance Tester

Fast. Accurate. Stable. Built for Modern Battery Manufacturing.

In battery manufacturing, every milliohm matters. Even a slight variation in internal resistance can directly affect battery consistency, cycle life, charging efficiency, thermal performance, and overall product reliability. The HongCe High Precision Battery Internal Resistance Tester is designed to help manufacturers identify these variations quickly and accurately.

Developed by HongCe, a professional manufacturer of Battery Testing Equipment, the HC-BTEM005 combines high-speed measurement, exceptional accuracy, and intelligent data management into one compact instrument. It provides simultaneous testing of AC Internal Resistance and DC Voltage, making it ideal for production lines, laboratories, incoming quality inspection (IQC), outgoing quality control (OQC), and R&D applications.

Why Internal Resistance Testing Matters

Battery voltage alone cannot fully reflect battery quality.

Internal resistance is one of the most important indicators of battery health. It directly influences:

Battery charging efficiency
Heat generation during operation
Energy conversion efficiency
Cycle life
Capacity consistency
Safety performance
Production yield
etc.

A high-precision internal resistance tester allows manufacturers to detect defective cells before assembly, reducing production costs and improving product reliability.

Product Highlights

Simultaneous Internal Resistance & Voltage Testing

The HC-BTEM005 measures both AC Internal Resistance and DC Voltage in a single operation, greatly reducing inspection time while ensuring highly consistent measurement results.

High-Speed Measurement for Production Lines

Testing speeds of up to 50 measurements per second make this instrument ideal for automated manufacturing environments where thousands of battery cells are inspected every hour.

Exceptional Measurement Accuracy

Designed for precision battery manufacturing, the tester provides:

Internal Resistance Accuracy: ±0.3%
Voltage Accuracy: ±0.05%

These specifications help manufacturers maintain strict quality standards throughout production.

Wide Measurement Range

The instrument supports batteries from miniature button cells to large energy storage batteries.

Internal Resistance: 0.001 mΩ – 3.2 kΩ
DC Voltage: 0V – 60V

Automatic and manual range switching ensures accurate measurements across different battery types.

Applicable Battery Types

Cylindrical Lithium-ion Batteries
Prismatic Lithium Batteries
Pouch Cells
Lithium Iron Phosphate (LiFePO₄) Batteries
Ternary Lithium Batteries
Sodium-ion Batteries
Nickel Metal Hydride Batteries
Nickel Cadmium Batteries

For more adaptation types, please contact us! ! !

International Reference Standards

Standard	Description
IEC 61960 Series	Secondary lithium cells and batteries for portable applications
IEC 62660 Series	Secondary lithium-ion cells for electric vehicles
IEC 62133-2	Safety requirements for portable sealed secondary lithium cells and batteries
UN 38.3	Lithium battery transportation testing support
ISO 12405 Series	Electrically propelled vehicles — Lithium-ion battery pack and system testing

Technical Specifications

Item	Specification
Model	HC-BTEM005
Display	4-Color VFD Display
Test Parameters	AC Internal Resistance, DC Voltage
Measurement Accuracy	Internal Resistance: ±0.3%; Voltage: ±0.05%
Internal Resistance Range	0.001 mΩ – 3.2 kΩ
Voltage Range	0V – 60V
Range Switching	Automatic & Manual Full Range
Testing Speed	3, 15, 50 measurements/second
Calibration	Full-Range Short-Circuit Zero Calibration
Comparator	30 Groups of Comparator Records, Bin Counting
Trigger Modes	Internal, Manual, External, Bus Trigger
Communication	RS-232, RS-485, Optional Handler Interface
Power Supply	AC190V–256V, 47Hz–63Hz
Rated Power	15VA
Functions	Keyboard Lock, Data Storage, REL Function
Dimensions	385 * 249 * 102 mm
Weight	Approx. 3.5 kg
Standard Accessories	Test Leads, Power Cable, Standard Accessories

Core Technologies

Kelvin Four-Wire Measurement

Minimizes contact resistance influence for more accurate testing.

High-Speed Digital Sampling

Captures stable measurement values even during rapid testing.

Intelligent Comparator Algorithm

Automatically classifies batteries according to preset tolerance values.

Automatic Range Switching

Optimizes measurement resolution without operator intervention.

Testing Items

AC Internal Resistance
DC Voltage
Battery Consistency
Cell Matching
Voltage Uniformity
Internal Resistance Uniformity

Frequently Asked Questions

Q1. What does the HC-BTEM005 measure?

It simultaneously measures AC internal resistance and DC voltage.

Q2. Is it suitable for lithium batteries?

Yes. It supports cylindrical, pouch, prismatic, and LiFePO₄ batteries, among others.

Q3. Can it be connected to an automated production line?

Yes. RS-232, RS-485, and an optional Handler interface support automation integration.

Q4. What is the maximum testing speed?

Up to 50 measurements per second.

Q5. Does it support automatic sorting?

Yes. The built-in comparator provides PASS/FAIL judgment and grading.

Q6. Can test data be stored?

Yes. It includes data storage and relative (REL) functions.

Q7. Is calibration supported?

Yes. Full-range short-circuit zero calibration is provided.

Q8. What industries commonly use this tester?

Battery manufacturing, EV batteries, energy storage, consumer electronics, laboratories, and research institutes.

About HongCe

HongCe is a professional manufacturer specializing in IEC Test Equipment, Battery Testing Equipment, Environmental Test Chambers, and customized laboratory testing solutions. From product design and precision manufacturing to technical support and after-sales service, HongCe delivers reliable equipment that helps customers improve product quality and testing efficiency.

With continuous investment in R&D and manufacturing technology, HongCe has become a trusted partner for testing laboratories, certification organizations, universities, and industrial manufacturers worldwide.
